I got a Grizzly G8688 7x12 Metal lathe

Signed-In Members Don't See This Ad

keithbyrd

Member
Joined
Sep 2, 2011
Messages
2,161
Location
Mount Wolf, PA
SO I got the metal lathe- been wanting to do this for a long time! Here is the problem. I know almost nothing about metal lathes!
So any tips, tricks, video sources etc would be greatly appreciated!!
Those who use metal lathe for pen turning - what cutters do you use?

Thanks folks!

Signed-In Members Don't See This Ad

jalbert

Member
Joined
May 17, 2015
Messages
767
Location
Louisville, KY
Congrats. I started out with this lathe and made many pens on it: a good portion of those being reasonably complex. This lathe will serve you well. One upgrade I would make ASAP is a quick change tool post. Little machine shop sells them, and they are a godsend. this one should be compatible with your lathe.



Dalecamino

Member
Joined
Jan 2, 2008
Messages
14,115
Location
Indianapolis, In.
Congratulations Keith. This will help you get started also.

To go along with the QCTP John has posted, you can look for a set of Indexable turning tools on ebay to save some bucks. Otherwise LMS has a set for $150.00 LMS is a good source for all your metal lathe needs. But then so is ebay.


magpens

Member
Joined
Feb 2, 2011
Messages
15,014
Location
Coquitlam, BC, Canada
@keithbyrd - CONGRATULATIONS on your new lathe !!! . . . You are going to have MUCH FUN with it !! . A Sieg lathe by the looks . . like mine !

I do NOT recommend buying the multi-shaped cutter sets that are commonly sold in a variety pack by some vendors -- you don't need most that are in the set - - and besides that, those variety-pack carbide cutters tend to break easily and often. . The pack may not even include a round.

I see such a set (red) in the picture you showed.

The cutting tool that I have used for 10 years (some infrequent replacements during that period) is a round carbide cutter, 11 mm diameter, supplied by Global Tooling in Portland, OR, and fitted to a straight 5/16 tool holder bar (not quite square cross section) which was made by Ken Ferrell (IAP member who I have not seen on-line for several years now).

I would suggest that you try to get Rick Herrell ( Username: rherrell ) to make a cutter like this for you, using the same Global Tooling carbide.
I order from Global Tooling by phone, as needed. . The people there are very helpful and very prompt to ship.

I use this cutter for everything I make.- "plastic", wood, aluminum and brass. . . It is a superb workhorse for pens !!!

I believe this is the cutter that I buy, as needed. . . I will check to be sure - - contact me directly for further info.


Last edited:

keithbyrd

Member
Joined
Sep 2, 2011
Messages
2,161
Location
Mount Wolf, PA
Congrats. I started out with this lathe and made many pens on it: a good portion of those being reasonably complex. This lathe will serve you well. One upgrade I would make ASAP is a quick change tool post. Little machine shop sells them, and they are a godsend. this one should be compatible with your lathe.

Thanks for the input and link!


keithbyrd

Member
Joined
Sep 2, 2011
Messages
2,161
Location
Mount Wolf, PA
Congratulations Keith. This will help you get started also.

To go along with the QCTP John has posted, you can look for a set of Indexable turning tools on ebay to save some bucks. Otherwise LMS has a set for $150.00 LMS is a good source for all your metal lathe needs. But then so is ebay.
Thank Chuck! will do some research!


keithbyrd

Member
Joined
Sep 2, 2011
Messages
2,161
Location
Mount Wolf, PA
@keithbyrd - CONGRATULATIONS on your new lathe !!! . . . You are going to have MUCH FUN with it !! . A Sieg lathe by the looks . . like mine !

I do NOT recommend buying the multi-shaped cutter sets that are commonly sold in a variety pack by some vendors -- you don't need most that are in the set - - and besides that, those variety-pack carbide cutters tend to break easily and often. . The pack may not even include a round.

I see such a set (red) in the picture you showed.

The cutting tool that I have used for 10 years (some infrequent replacements during that period) is a round carbide cutter, 11 mm diameter, supplied by Global Tooling in Portland, OR, and fitted to a straight 5/16 tool holder bar (not quite square cross section) which was made by Ken Ferrell (IAP member who I have not seen on-line for several years now).

I would suggest that you try to get Rick Herrell ( Username: rherrell ) to make a cutter like this for you, using the same Global Tooling carbide.
I order from Global Tooling by phone, as needed. . The people there are very helpful and very prompt to ship.

I use this cutter for everything I make.- "plastic", wood, aluminum and brass. . . It is a superb workhorse for pens !!!

I believe this is the cutter that I buy, as needed. . . I will check to be sure - - contact me directly for further info.

Thanks Mal - I appreciate the input and the links!


Dehn0045

Member
Joined
Mar 19, 2017
Messages
1,514
Location
Houston, Texas
I have found the youtube machining community to be pretty plentiful. Some of the channels that I like include: Blondihacks, oxtoolco, this old tony, mrpete222, keith rucker, abom79, joe pieczynki, woods creek workshop, frank hoose. I think most of the channels/creators will do at least some of the beginner topics, but sometimes it is fun to learn about the more advanced techniques and specialized tools to get a more well rounded understanding of the topic.
