Finishing Help with this please ..... needs to be completed by Thursday

Signed-In Members Don't See This Ad

Rob9

Member
Joined
Jan 18, 2018
Messages
6
Location
Toronto, Ontario
I've made about 20 pens so I'm just starting to feel a bit comfortable. A good friend just finished a race and his time was 9:58:47 for an Ironman. I wanted to put that on a wooden pen for him but I don't know how. Can I just write it on with a sharpie and then apply a CA glue finish over it? Please help ... I don't have time to practice so hopefully your suggestions will be borderline "foolproof". Sorry for this last minute request but this would be the perfect gift for him.

Thanks for your help.

Cheers,
Rob in Toronto

Signed-In Members Don't See This Ad

EricRN

Member
Joined
May 16, 2019
Messages
53
Have you considered having it professionally engraved on the pen? You could turn it down and, before you finish it, take it to an engraver. Fill the void with thick CA (or some other inlay material if you want to get fancy) sand or flush and then finish with CA.


jttheclockman

Member
Joined
Feb 22, 2005
Messages
12,655
Location
NJ, USA.
Not a good idea to rush is my opinion. Your intentions are good but no need to do something in haste. If he gets it later so what. The idea of sharpie is not a good one in my opinion also because it looks cheap. The problem here is your expertise. I can make suggestions but your ability comes into question. For me with something like this you can have something like name and times burned in using a laser if you knew someone willing to do this. Maybe get with a member here. Or you can do a decal with name, time and maybe a photo but again you would have to know how to do this and it takes time to practice. But if you want foolproof you need to service out the project for a blank and hope someone can help and in time. That is the best I have for you.


Dalecamino

Member
Joined
Jan 2, 2008
Messages
13,041
Location
Indianapolis, In.
Locate a local Trophy Shop, and ask if they can engrave it for you. Depending on the wood you use, you may not need to fill in. If it's a light colored wood, and they use a laser, the burn marks will stand out. If they use a carver head on light wood, you may have to fill in with Rub-n-Buff (available at craft stores) Using Dark wood, you will likely need the Rub-n-Buff, which comes in assorted colors. Some people use paint for this. Good luck!


greenacres2

Member
Joined
May 2, 2017
Messages
976
Location
Northwest IN
CA will definitely eat Sharpie, and many if not most paints. My wife has hand painted some blanks after i've turned them--then a week or so later i add a few coats spray lacquer. Then, a few days to cure, sand and either reapply or finish with CA over the top of the lacquer.
Laser engraving would be my choice on this, and potentially fit your time frame if it's someone you could drive to. I'd turn 2 or 3 blanks so that if their focus is off the first time you save a trip.
earl


Rob9

Member
Joined
Jan 18, 2018
Messages
6
Location
Toronto, Ontario
Many thanks for the quick responses with detailed answers. Good bye sharpie idea and hello to an engraver! Also the suggestions of wood, light versus dark, are much appreciated. So now I'll be online looking for an engraver. Again, thanks so much.

Cheers,
Rob


Dalecamino

Member
Joined
Jan 2, 2008
Messages
13,041
Location
Indianapolis, In.
Many thanks for the quick responses with detailed answers. Good bye sharpie idea and hello to an engraver! Also the suggestions of wood, light versus dark, are much appreciated. So now I'll be online looking for an engraver. Again, thanks so much.

Cheers,
Rob
You're welcome! So check back in here and let us know how it goes.


Rob9

Member
Joined
Jan 18, 2018
Messages
6
Location
Toronto, Ontario
Not the best solution - how about a clear slide on label label with dark printing?
Hi Tony ..... I was initially thinking about using something like Letraset on the pen but couldn't figure out how to apply a finish such as French polish and a couple of coats of wax and still keep the letraset numbers in place without having them come off when applying the polish and wax. And if I finish it first and then apply the letraset numbers I imagine that these numbers could easily wear off.

I just talked to an engraver who lives nearby and does laser work and is familiar with working with wooden pens. He said the turn around time is 5 business days and the cost would be approximately $50 - $70. He has done this before and knows what he is doing so it might be worth the $$.

Thanks for your suggestion.

Cheers,
Rob


alanemorrison

Member
Joined
Jan 15, 2019
Messages
305
Location
N Ireland
I just talked to an engraver who lives nearby and does laser work and is familiar with working with wooden pens. He said the turn around time is 5 business days and the cost would be approximately $50 - $70. He has done this before and knows what he is doing so it might be worth the $$.
Rob
That quote seems somewhat high for one pen. It will be an expensive gift.


randyrls

Member
Joined
Feb 2, 2006
Messages
4,207
Location
Harrisburg, PA 17112
For me with something like this you can have something like name and times burned in using a laser if you knew someone willing to do this.
I would add the Race Name and Date.
NB: I Made a pen for a friend who became a US Citizen. Ken Nelson Kallenshaans Woods engraved the Pledge of Allegiance on the cap of the US Flag themed pen.

Joined
Dec 22, 2017
Messages
851
Location
Wolf Creek Montana
WOW!!! That is expensive. Maybe instead of turning pens and making knives I should go into the engraving business. I just recently bought a Nege 1500 off Amazon for around $85.00. Two pens at those prices and I've paid myself back for the cost of the laser.


EricRN

Member
Joined
May 16, 2019
Messages
53
WOW!!! That is expensive. Maybe instead of turning pens and making knives I should go into the engraving business. I just recently bought a Nege 1500 off Amazon for around $85.00. Two pens at those prices and I've paid myself back for the cost of the laser.
Is that thing easy to learn to use? Will it engrave metal, too, or just wood? How accurate is it? I never thought something like that could be had for $85. I was thinking it would be on the order of $1000 or more.


keithncsu

Member
Joined
May 28, 2016
Messages
362
Location
Catawba, SC 29704
The NEJE and other various names are great little machines. I used mine the other night to engrave my wife's new students' names on wooden discs. I didn't ask why, I just said yes 😂 . Did about 14 of them in a row in as big of a font as I could. No issues. Most people I've talked to/read about agree that the first laser that comes in them is cheap and will not last long. Replacements can be had for about $20 if I recall. I had to do that and it has been 2-3 years since the replacement and never needed another (yet). Also picked up a USB powered PC fan that I sit on top of the laser housing when in use. Not sure if that has helped with the lifespan of the replacement laser but I figure it can't hurt.

Joined
Dec 22, 2017
Messages
851
Location
Wolf Creek Montana
Is that thing easy to learn to use? Will it engrave metal, too, or just wood? How accurate is it? I never thought something like that could be had for $85. I was thinking it would be on the order of $1000 or more.
If you go to Amazon it will give you all the specs. I just got mine and haven't really messed around with it yet but the test piece I did was easy and all you do is set it up and turn it on and it does the rest. As for making my own artwork, I haven't done any of that yet.


ramaroodle

Member
Joined
Feb 15, 2018
Messages
249
Location
Seattle
Yes. You can buy a NEJE for $49 on Alibaba and do it yourself as often as you like.

Last edited:

Ironwood

Member
Joined
May 31, 2010
Messages
770
Location
Mackay. Australia
Yes. You can buy a NEJE for $49 on Alibaba and do it yourself as often as you like.
That sounds like a great option Andy. I had a look at one of the NEJE units on Aliexpress, it said that they couldn’t do acrylic. Does this mean all resin blanks are out, and it’s pretty much only good for writing on wooden blanks ?


keithncsu

Member
Joined
May 28, 2016
Messages
362
Location
Catawba, SC 29704
That sounds like a great option Andy. I had a look at one of the NEJE units on Aliexpress, it said that they couldn’t do acrylic. Does this mean all resin blanks are out, and it’s pretty much only good for writing on wooden blanks ?
In most cases that is correct. I think some folks have found ways to use these when engraving on acryclic/stabilized blanks using painters tape or coloring the area ahead of time with black Sharpie. I've read limited/mixed results on that but have never tried to duplicate it. I successfully engraved onto some stabilized tamarind one time though the engraving never got really dark even with going over it a couple times. It all has to do with the acrylic/stabilized blanks being too reflective and the laser bouncing off rather than penetrating/burning. But I'm certainly no expert on that matter. Most people have better luck doing water slide decals on acrylics/stabilized blanks to personalize.


Rob9

Member
Joined
Jan 18, 2018
Messages
6
Location
Toronto, Ontario
You're welcome! So check back in here and let us know how it goes.
He ended up charging me $40.00 and did it in a day. He said that the quote of $50-70 was for a same day job before he saw what I wanted. It was well done but I'll certainly look into a NEJE and see how that works.
